2 Core Silicone Rubber Coated Power Cable Multicore Flexible Insulated Strand Wire Cables 2.5mm

1). Conductor Material : Tinned Copper
2). Insulation Material : Silicone Rubber/FEP/PVC
3), Jacket Material: Silicone Rubber
3). Rated Temperature : -60°C~+200°C
4). Rated Voltage : 300/500V
5). Colors: Black,Red,White,Blue,Yellow,Green,Brown,Grey,Purple,orange,Green/Yellow

Product Description:
Item
Value
Place of Origin
China (Shanghai )
Brand Name
Selfu
Product Name
Silicone Rubber Cable
Type
Insulated
Application
Electric conduction
Conductor Material
Tinned copper
Conductor Type
Stranded
Conductor structure
0.08mm tinned copper or customized
Insulation Material
Siliccone Rubber
Model Number
0.2mmsq - 180mmsq
Features
Super soft, Excellent flexibility
Conductor characteristics
Oxidation Resistance
Working temperature
-60°C~+200°C
Customization
Customized service according to client's requirements
Color
Black,Red,White,Blue,Yellow,Green,Brown,Grey,Green/Yellow


FEATURE:
Core for the anti-oxidation tinned copper, copper wire bright light resistance has a good electrical conductivity, energy saving, durable, high security.
Wire sheath and insulation are made of ultra-soft silicone rubber (plus oil-resistant paper) with wear-resistant acid and alkali oil long life and other characteristics.

Silicone skin is soft, not easy to harden brittle and smooth surface.
Resistant to high and low temperature: -60℃ ~ +200℃


MODEL AND CODE DESCRIPTION:

YGC/YGZ: Silicone rubber insulated and sheathed power cable

YGCR: Silicone rubber insulated and sheathed flexible power cable for movable applications
YGCP: Silicone rubber insulated and sheathed copper braid shielded power cable
YGG2G: Silicone rubber insulated and sheathed power cable with steel tape armor
JGG: Silicone rubber insulated and sheathed installation wire
JGGR: Movable silicone rubber insulated and sheathed soft installation wire
JGGP: Silicone rubber insulated and sheathed, copper braid shielded installation wire
Y---- Series code (movable soft cable)
G---- Silicon rubber
C---- Heavy type
2---- Steel tape armor
P---- Copper braid shield
R---- Multi-strand conductor






Application

Indoor or outdoor use for the power supply of mobile or fixed equipment like mobile plants operating on building sites, pumps, portable toolings, power engines, cables reels, etension cables.

Wiring for high-temperature locations such as electronic equipment, heavy industry machinery, power installation, industrial machinery, and electric heating products, as well as internal connecting wires for microwave ovens, metallurgical, electrical, petrochemical, electric heating, industrial and other machinery, as well as instruments, gas appliances, new sources, and other high-temperature environments.
